P/N MS70108
Link
Webbing Width: 45mm
Weight 2oz
Plating: Zinc Plated
Proof Load 3000lbs
Material: Drop Forged Alloy Steel
|
 |
P/N 1274/1275
Latch and Link
Webbing Width: 45mm
Weight: 265g
Plating: Zinc
Proof Load: 3600lb
Min Breaking Load: 5000lb
Material: Forge Steel Heat Treated |
 |
PART NO. 48 B 7883
LINK, Connector, Parachute Harness
Drop Forged Alloy Steel
Proof-load 2,500 lbs.
Weight (approx.) 1.9oz. |
 |
PART NO. 59 C 381
LINK, TRIANGLE, REVERSIBLE QUICK FIT
Drop Forged Alloy Steel
Proof-Load 2,500 lbs.
Outside Dimension 2 3/8" x 2 9/16"
Weight (approx.) 3.5 oz. |
| PART NO. 6032 C
LINK, Assembly, Parachute Connector
Drop Forged Alloy Steel
Proof-Load 16,500 lbs.
Weight (approx.) 9.4 oz.
Height 2 3/8" (60mm)
Width 3 1/2" (89mm)
Finish with Chromate Treatment
Zinc Plate per ASTM B633, SC3
(FEZN 12), Type III (Clear or Colourless)
48 Hour Salt Spray Tested |
 |
PART NO. PS 22002-1
LINK, Parachute Removable Connector
Drop Forged Alloy Steel
Proof-Load 3,000 lbs.
Weight (approx) 2.6 oz.
Height 1 1/4" (31mm)
Width 2 13/16" (71mm)
Finish with Chromate Treatment
Zinc Plate per ASTM B633, SC3
(FEZN 12), Type II (Gold)
96 Hour Salt Spray Tested |
 |
PART NO. PS 22020-1
LINK, Parachute Harness Triangle
Drop Forged Alloy Steel
Proof-Load 2,500 lbs.
Weight (approx.) 1.5 oz.
Height 1 13/16" (46mm)
Width 1 3/4" (44mm)
Finish Zinc Plate per ASTM B633, SC3
(FEZN 12). Type III (Clear or Colourless)
48 Hour Salt Spray Tested
|
 |
PART NO. PS 70108
LINK, Parachute Connector
Drop Forged Alloy Steel
Proof-Load 3,000 lbs.
Weight (approx.) 2 oz. |
 |
PART NO. 55B6261
|
 |
PART NO. 6060
|
 |
PART NO. PS PS24553
|
